Human sperm immobilization effect of Carica papaya seed extracts: an in vitro study

Nirmal K Lohiya, Lalit K Kothari1, B Manivannan, Pradyumna K Mishra, Neelam Pathak

Reproductive Physiology Section, Department of Zoology, University of Rajasthan, Jaipur - 302 004, India
1Reproductive Medicine Clinic, 50 Gem Enclave, Malviya Nagar, Jaipur, India

Asian J Androl  2000 Jun; 2: 103-109


Keywords: human sperm; sperm immobilization; spermicidal agents; Carica papaya
Abstract
Aim: To examine if the seed extracts of Carica papaya, which showed antispermatogenic/sperm immobilization properties in animal models, could cause human sperm immobilization in vitro. Methods: Chloroform extract, benzene chromatographic fraction of the chloroform extract, its methanol and ethyl acetate sub-fractions and the isolated compounds from the sub-fractions i.e., ECP 1 & 2 and MCP 1 & 2, of the seeds of Carica papaya were used at concentrations of 0.1%, 0.5%, 1% and 2%. Sperm motility was assessed immediately after addition of extracts and every 5 minutes thereafter for 30 minutes. Results: There were dose-dependent spermicidal effects showing an instant fall in the sperm motility to less than 20% at 2% concentration. Isolated compounds ECP 1 & 2 were more effective inducing a motility of less than 10%. Many of the spermatozoa became vibratory on the spot. Total inhibition of motility was observed within 20-25 min at all concentrations of all products. Scanning and transmission electron microscopy revealed deleterious changes in the plasma membrane of the head and mid-piece of spermatozoa. Sperm viability test and the number of abnormal spermatozoa after completion of incubation suggested that the spermatozoa were infertile. The effects were spermicidal but not spermiostatic as revealed by the sperm revival test. Conclusion: The results reveal spermicidal activity in vitro of the seed extracts of Carica papaya.

1 Introduction

Several  plants which induce male antifertility, also possess spermicidal properties[1]. Setty et al[2] reported that out of 160 plant extracts tested for in vitro spermicidal activity at 2% concentration in rats and human spermatozoa, 30 plants showed spermicidal properties and 16 of them caused an instant human sperm immobilization. We have found earlier that out of various extracts of the seeds of Carica papaya tested for contraceptive efficacy, the chloroform extract and the partially purified benzene chromatographic fraction of the chloroform extract produced sperm motility inhibition in rats[3,4] and azoospermia in rabbits[5,6]. Methanol and ethyl acetate sub-fractions of the benzene chromatographic fraction also had similar effects in rats and rabbits and a sperm motility inhibitory action in langur monkeys (unpublished observations, Lohiya et al). The effects were systemic, resulting from oral administration of the seed extract/products and were free of toxicity. The chloroform extract of the seeds of Carica papaya has also been shown to possess in vitro spermicidal properties in rat, rabbit, and monkey spermatozoa[7]. In the present study, the Carica papaya seed extracts  which showed contraceptive efficacy in animal models were examined for their sperm immobilization effects in vitro, in human spermatozoa with a view to their potential as vaginal spermicidal contraceptives.

2 Materials and methods

2.1 Test materials

The seeds of Carica papaya (Caricaceae,Voucher No. RUBL 16590) of honey dew variety, were examined using the extraction procedures described earlier[6]. Briegly, the seeds of Carica papaya were shade-dried, powdered and soxhalated in chloroform at 58 for 123 hours. The soxhalated material was concentrated under reduced pressure and further purified by silica gel column chromatography using benzene, chloroform and ethyl acetate as eluents. Following partial purification, the benzene chromatographic fraction, which showed significant effect on semen parameters[4,6], was subjected to methanol and ethyl acetate sub-fractionation and the residues after evaporation of the solvents were used for further purification by Thin Layer Chromatography (TLC). Two compounds were obtained from each sub-fraction on TLC viz., MCP 1 & 2 and ECP 1 & 2, respectively. The compounds were scraped, extracted with the corresponding solvents, evaporated to dryness under reduced pressure and the residues were separated. The chloroform extract, the benzene chromatographic fraction of the chloroform extract and its methanol and ethyl acetate sub-fractions and the isolated compounds MCP 1 & 2 and ECP 1 & 2 which showed significant effects on sperm parameters by oral administration in rats and rabbits[3,5,6], were used in the present investigation for in vitro sperm motility assessment. The extract, fractions and compounds were dissolved in Biggers Whitten and Whittingham (BWW) medium, supplemented with sodium bicarbonate (210 mg/L), glucose (100 mg/L), sodium pyruvate (3 mg/mL), bovine serum albumin (300 mg/L), sodium lactate (0.37 mL), benzyl penicillin (10,000 U/mL) and HEPES buffer (2 mL) at concentrations 2%, 1%, 0.5% and 0.1%.

2.2 Sample preparation

Semen samples (n=15) from normal subjects after 48 hours of sexual abstinence were subjected to routine semen analysis[8] following liquefaction at 37. Sperm counts above 50 million/mL with normal morphology, rapid and linear and progressive motility, and viability above 50% was considered for the in vitro test. WHO's strict evaluation criteria were followed for assessing sperm morphology[8]. Spermatozoa free of seminal plasma were obtained by centrifugation, washed once in BWW media and adjusted to the final concentration of 50 million/mL.

2.3 Experimental procedure

Prior to experiment, semen samples and the seed extract/product preparations were prewarmed to 37; 250 L semen sample containing 15 million spermatozoa was added to 250 L of the extract preparation at various concentrations. Sperm motility (a, b, c & d grades)[8], was assessed immediately after addition of the semen samples and thereafter every 5 min for up to 30 min in a phase contrast microscope along with placebo control. Following completion of the experiment, sperm viability and morphological assessments were carried out by nigrosin-eosin and papanicolaou staining methods, respectively[8].

2.4 Ultrastructural studies

Following completion of motility assessment, the spermatozoa were separated by centrifugation, washed with phosphate buffer (0.1 mol/L; pH 7.2) and pelleted by centrifugation. The pellets were immediately fixed in 2.5% glutaraldehyde in phosphate buffer for 30 min and washed thrice in phosphate buffer. For scanning electron microscopy (SEM), a thin film of spermatozoa was smeared on an SEM stub with silver paint, air dried, sputter coated with gold and observed under the scanning electron microscope (Leo SEM 435 VP). For transmission electron microscopy (TEM), the spermatozoa pellet was post-fixed in OsO4 for 30 min, washed in phosphate buffer, followed by distilled water, dehydrated in acetone, embedded in low viscosity spur medium and polymerized at 60 for 48 h. The ultrathin sections were stained with uranyl acetate and lead citrate and observed under the transmission electron microscope (Philips model CM-10).

2.5 Sperm revival test

Following completion of the experiment, the spermatozoa were washed twice with BWW medium and incubated once again in the same medium free of extract/products at 37 for 30 min to observe revival of sperm  motility, if any. Immotile spermatozoa showing vibratory movement to progressive motility after incubation were considered revived.

2.6 Statistical analysis

Student's t-test was employed for statistical comparison.

3 Results

Sperm motility from its initial level of 55.07%3.30% dropped immediately following the addition of the chloroform extract, benzene chromatographic fraction and its sub-fractions as well as the isolated compounds, ranged between 8.3%0.7% and 31.2%1.5%. The effects were dose-dependent and more pronounced effects were observed with the compounds isolated from the ethyl acetate sub-fractions (ECP 1 & 2). Although many of the spermatozoa showed only vibratory movement after 5 min of addition of the drugs, particularly at 2% concentration, total inhibition of motility was observed after 10 min in the chloroform extract, benzene chromatographic fraction of the chloroform extract and ECP 1 & 2 treated samples. None of the spermatozoa showed motility, 25 min after addition of the extract/fractions/compounds (Tables 1 & 2).

The viability of spermatozoa, following completion of the experiment, fell significantly (P<0.001; Range 22.8%0.6% to 45.4%1.2% as against 54.9%1.2% in control) and the effects were more pronounced in the ECP 1 & 2 treated samples at 2% concentration. Sperm abnormality showed a significant increase in its pattern (P<0.001; Range 26.7%1.1% to 46.9%1.3% as against 16.6%1.8% in  control samples). Most abnormalities were found in MCP 1 & 2 treated samples at 2% concentration (Table 3).

Table 1.Human sperm motility (%) following incubation with chloroform extract, bezene chromatographic fraction and its sub-fractions of the chloroform extract of the seeds of Carica papaya in vitro (meanSEM of 15 samples)*.

Extract/Fraction

Concentration
of Extract(%)

Time (min)

0

5

10

15

20

25

Control

-

55.073.30

54.282.60

54.012.51

53.992.53

53.852.50

53.632.45

Chloroform extract

2.0

17.921.89

4.781.40

Nil

-

-

-

1.0

21.711.88

10.281.40

1.780.73

Nil

-

-

0.5

25.352.42

15.141.80

7.071.40

2.210.96

Nil

-

0.1

28.422.47

17.851.62

9.711.23

3.421.16

0.710.08

Nil

Benzene
chromatographic
fraction of
chloroform extract

2.0

10.851.64

1.780.09

Nil

-

-

-

1.0

16.141.97

5.420.96

0.570.07

Nil

-

-

0.5

20.142.91

10.571.71

3.851.15

0.710.08

Nil

-

0.1

24.782.70

14.851.65

9.141.35

3.211.06

Nil

-

Ethyl acetate sub-
fraction of the
benzene chroma-
tographic
fraction of
chloroform extract

2.0

13.851.63

4.641.67

0.710.48

Nil

-

-

1.0

17.071.87

7.781.54

2.211.07

Nil

-

-

0.5

20.642.10

10.851.34

6.001.19

1.070.53

Nil

-

0.1

24.202.44

14.141.43

8.140.74

2.000.63

Nil

-

Methanol subfrac-
tion of the benzene
chromatographic
fraction of chloro-
form extract

2.0

15.851.94

6.501.42

2.140.86

Nil

-

-

1.0

18.851.74

10.851.19

4.640.98

0.710.08

Nil

-

0.5

24.001.78

13.711.47

8.280.84

3.280.84

Nil

-

0.1

28.141.87

17.571.53

11.421.14

6.140.96

0.420.03

Nil

*All values are statistically significant to control (P<0.001)

Table 2. Human sperm motility (%) following incubation with the partially purified compounds of the sub-fractions of the bezene chromotographic fraction of the seeds of Carica papaya in vitro (meanSEM of 15 samples)*.

Compound

Concentration
(%)

Time (min)

0

5

10

15

20

25

ECP1

2.0

8.30.7

5.70.9

0.20.04

Nil

-

-

1.0

12.20.6

7.10.8

1.50.60

Nil

-

-

0.5

16.20.6

10.60.8

4.00.79

Nil

-

-

0.1

20.30.5

11.01.0

6.50.66

1.60.57

Nil

-

ECP2

2.0

9.50.7

4.30.8

Nil

-

-

-

1.0

12.30.8

5.71.0

1.20.54

Nil

-

-

0.5

17.31.0

10.71.2

4.60.72

0.40.07

Nil

-

0.1

22.70.7

15.31.3

7.41.16

2.50.85

Nil

-

MCP1

2.0

16.30.6

10.41.1

5.50.95

1.110.69

Nil

-

1.0

20.71.0

12.61.6

8.61.06

2.440.88

Nil

-

0.5

27.31.2

18.31.8

13.11.67

8.331.56

2.220.87

Nil

0.1

31.21.5

21.62.0

15.71.76

9.221.57

3.001.19

Nil

MCP2

2.0

17.31.4

10.61.6

5.10.88

1.00.06

Nil

-

1.0

21.41.6

11.51.4

10.12.09

4.41.14

1.10.07

Nil

0.5

25.81.6

17.22.2

13.52.18

6.21.07

1.80.05

Nil

0.1

31.11.7

20.21.6

15.01.4

88.80.88

4.30.89

Nil

*All values are statistically significant to control (P<0.001)

Table 3. Sperm viability and abnormalities following incubation with chloroform extract, bezene chromatographic fraction, its sub-fractions and isolated compounds of the chloroform extracts of the seeds of Carica papaya in vitro (meanSEM of 15 samples)*.

Parameters

Concentra-
tion of the
Extract
(%)

Control

Chloroform
extract

Benzene
chromato-
graphic
fraction

Ethyl-
acetate sub-
fraction

Methanol sub-
fraction

ECP1

ECP2

MCP1

MCP2

Viability
(%)

2



28.11.8

24.82.1

27.92.2

29.71.6

23.31.3

22.80.6

29.31.1

31.60.8

1

54.91.2

29.51.5

27.62.2

29.82.0

31.41.5

27.21.0

28.70.8

34.21.4

36.20.8

0.5



31.81.7

30.22.5

32.41.8

33.01.8

31.01.2

33.61.1

38.41.3

41.31.0

0.1



34.22.0

33.12.1

35.52.0

35.91.5

33.61.0

37.01.1

41.31.4

45.41.2

Abnormal Sperm (%)

2



36.92.0

30.31.6

30.52.6

30.32.0

39.40.9

39.01.1

46.71.2

46.91.3

1

16.61.8

33.62.1

29.42.1

29.01.9

29.02.1

35.71.2

37.21.3

40.81.2

45.91.3

0.5



32.92.0

29.12.3

29.12.3

27.71.7

31.20.9

32.81.1

37.31.2

40.30.9

0.1



32.71.7

28.42.8

28.92.4

27.41.6

26.71.2

26.71.1

33.21.2

35.11.0

*All values are statistically significant to control (P<0.001).

3.1 Ultrastructure of Spermatozoa

3.1.1 Scanning Electron Microscopy (SEM)

The SEM of normal human spermatozoa showed an oval head with distinct acrosomal and post-acrosomal regions and well defined outer plasma membrane. The mid-piece was long, slender, encircled with a distinct concentric mitochodrial sheath. The tail region separated  from the mid-piece by a distinct groove, annulus (Figure 1). After completion of treatment in vitro with extract/fraction/compounds of the seeds of Carica papaya at 2% concentration, the spermatozoa depicted typical changes particularly at the level of mid-piece and acrosome. Bent mid-piece was the common observation. Membrane damage in the acrosome was also evident resulting in acrosome ballooning (Figure 2).

Figure 1. SEM of the human spermatozoa from the placebo control samples. The sperm appears with intact plasma membrane. 7,600.
Figure 2. SEM of the human spermatozoa following in vitro treatment (30 min at 2% ) with compound ECP 1 of Carica papaya showing membrane damage in the mid-piece and acrosome, resulting into bent mid-piece and acrosome ballooning. 5,000.

3.1.2 Transmission Electron Microscopy (TEM)

The human spermatozoa, prior to treatment, under TEM showed a triangular head with distinct acrosomal envelope. The nucleus contained condensed chromatin material. The neck region was short containing segmental  columns,  connecting  the head and mid-piece. The mid-piece contained well defined mitochondrial sheath surrounding the axoneme (Figure 3).

Figure 3. TEM of normal spermatozoa from control sample, showing intact acrosome and mid-piece. 5,600.

After completion of the treatment in vitro the head of the spermatozoa showed deleterious changes. The typical observation was severe membrane damage in the acrosome resulting in leach out of the acrosomal contents. The nucleus appeared vacuolated and the mid-piece configuration was severely damaged (Figure 4). The morphological changes of the spermatozoa were uniform in all the extract/products treated samples at 2% concentration.

Figure 4. TEM of the human spermatozoa following in vitro treatment (30 min at 2%) with compound ECP 1 of Carica papaya showing membrane damage in the mid-piece and acrosome. 7,600.

3.2 Sperm Revival Test

None of the spermatozoa which were 100% immotile prior to the revival test recovered any motility following 30 minutes incubation with BWW medium.

4 Discussion

The mechanism of action of many of the spermicidal compounds of plant origin seems to be by surface action, disrupting the plasma membrane of the spermatozoa[1]. The currently used vaginal spermicide, nonoxynol-9 acts in a similar manner. It produces disruption of lipids within the sperm membrane, particularly on the acrosome and mid-piece, causing disruption and rapid loss of sperm motility[9,10]. Praneem, a polyherbal cream  containing purified neem seed extract, quinine hydrochloride and the reetha saponins extracted from the  pericarp of Sapindus mukorossi, at 10% concentration has high potency to modify the mucus and inhibit the penetration of sperm[15]. Inhibition of the sperm specific enzymes acrosin and hyaluronidase, which play  an important role in the fertilization process by plant derivatives, has also been reported[1]. It is believed that the flavonoids and their derivatives, flavonones and flavonols, contain hyaluronidase inhibitory activity[1].

Farnsworth and Waller[1] have screened a large number of plants for spermicidal  and reported that a majority of plant-derived spermicides are triterpene saponins of several structural types, flavonoids and phenol compounds. The saponins of Cyclomen persicum, Primula vulgaris and Gypsophyla paniculata have been reported  to produce instant immobilization of human spermatozoa within 20 seconds[11]. Acacic acid from the bark of Acacia concinna, oleanolic acid and porceric acid from the roots of Albizza procera and anagalligenone from the whole plant Anagallis arvensis also produce instant sperm immobilization within one minute in human spermatozoa[12]. An instant spermicidal activity of pittoside A & B, the sapogenins isolated from the plant Pittosporum nilghirense has also  been reported[13].

In the present study the chloroform extract, the benzene chromatographic fraction of the chloroform extract and its methanol and ethyl acetate sub-fractions and the isolated compounds, ECP 1 & 2 and MCP 1 & 2, which exerted their systemic action on the sperm parameters in our earlier studies, have also shown a sperm immobilizing effect on human spermatozoa in vitro. The effect is spermicidal and not spermiostatic as there is no revival of motility after incubation with BWW medium free extracts. The isolated compounds ECP 1 & 2 were found to be more effective, lowering the motility to less than 10%, immediately after addition of the compound at 2% concentration. SEM and TEM of spermatozoa after completion of incubation  showed membrane damage in the head as well as mid-piece suggesting that the mode of action appears similar to that of nonoxynol-9[9,10] and most other herbal spermicidal agents[1]. Although not specific, the membrane damage in the sperm head could cause acrosin and hyaluronidase inhibition as well, as reported for other herbal spermicides[1].

The sperm immobilizing effect was dose-dependent. However, instant immobilization of spermatozoa has not been observed in the present study, although the compounds ECP 1 & 2 drastically affected the sperm motility to less than 10% and most of them showed slow progressive to vibratory movement that may imply infertility in fertility trials[8]. A still higher concentration may induce instant immobilization as in CONSAP, a herbal cream formulation containing saponins of fruit pericarp of Sapindus mukorossi where 2.5% concentration has been tested in woman volunteers[14].

A possibly useful approach may be a combination of Carica papaya products with other spermicides as in praneem, where the combination of purified neem seed extract, reetha saponins and quinine HCl dispensed in a water washable  cream base has been tried, for a better applicability[15]. Such a combination approach should, in addition to the  instant sperm immobilization action, contain an antimicrobial action too, as in praneem which reportedly contains  antimicrobial action against the vaginal pathogens Chlamydia trachomatis, Candida albicans and Gardeneralla vaginalis tested in vitro in phase I clinical trial[15]. Importantly, the leaves/seeds/root/fruit extracts of Carica papaya are reported to possess antibacterial, antiviral and antiyeast activities[16,17]. These extracts were particularly sensitive to Candida albicans, tobacco mosaic virus, ring spot virus and a number of bacteria which includes Salmonella, Staphylococcus and Pseudomonas species[16]. This would be an added advantage for any Carica papaya-based vaginal contraceptive. These extracts were particularly advantageous over nonoxynol-9, that it does not cause inflammatory reaction and irritation of vaginal epithelium upon repeated use (unpublished observations, Lohiya et al). Further studies are in progress with a combination approach and its possible antimicrobial action for a better applicability.

5 Acknowledgements

The investigation was supported by the Ministry of Health and Family Welfare (MHFW), Government of India, New Delhi and the Special Assistance Programme (SAP/DSA II Phase), University Grants Commission, New Delhi. Ultras tructural studies were carried out at the Regional Sophisticated Instrument Facility for Electron Microscopy, Department of Anatomy, All India Institute of Medical Sciences (AIIMS), New Delhi.

References

[1] Farnsworth NR, Waller DP. Current status of plant products reported to inhibit sperm. In: Zatuchni GI, editor. Research frontiers in fertility regulation 1982; 2: 1-16.
[2] Setty BS, Kamboj VP, Khanna NM. Screening of Indian plants for biological activity: Part VII-spermicidal activity of Indian plants. Ind J Exp Biol 1977; 15: 231-2.
[3] Lohiya NK, Goyal RB. Antifertility investigations on the crude chloroform extract of Carica papaya Linn. seeds in male albino rats. Ind J Exp Biol 1992; 30: 1051-5.
[4] Pathak N, Mishra PK, Manivannan B, Lohiya NK. Sterility due to inhibition of sperm motility by oral administration of benzene chromatographic fraction of the chloroform extract of the seeds of Carica papaya in rats. Phytomedicine  (In press).
[5] Lohiya NK, Pathak N, Mishra PK, Manivannan B. Reversible contraception with choloroform extract of Carica papaya Linn. seeds in male rabbits. Reprod Toxicol 1999; 13: 59-66.
[6] Lohiya NK, Mishra PK, Pathak N, Manivannan B, Jain SC. Reversible azoospermia by oral administration of the benzene chromatographic fraction of the chloroform extract of the seeds of Carica papaya in rabbits. Advances in Contraception 1999; 15: 141-61.
[7] Goyal RB. Post-testicular antifertility effects of Carica papaya seed extracts. Ph.D. Thesis, University of Rajasthan, Jaipur, India, 1991.
[8] WHO Laboratory manual for the examination of human semen and sperm-cervical mucus interaction. 4th ed. Cambridge: Cambridge University Press; 1999.
[9] Schill WB, Wolff HH. Ultrastructure of human spermatozoa in the presence of the spermicide nonoxynol-9 and a vaginal contraceptive containing nonoxynol-9. Andrologia 1981; 13: 42-9.
[10] Wilborn WH, Hahn DW, McGuire JJ. Scanning electron microscopy of human spermatozoa after incubation with the spermicide nonoxynol-9. Fertil Steril 1983; 39: 717-9.
[11] Primorac M, Sekulovic D, Antonic S. In vitro determination of the spermicidal activity of plant saponins. Pharmazie 1985; 40: 585.
[12] Kamboj VP, Dhawan BN. Research on plants for fertility regulation in India. J Ethnopharmacol 1982; 6: 191-226.
[13] Jain GK, Pal R, Khanna NM. Spermicidal saponins from Pittosporum nilghirense Wight et Apnott. Ind J Pharm Sci 1980; 42: 12-3.
[14] Kamboj VP, Dhawan BN. Fertility regulating plants on Indian scene-an update. Contraceptive Research Today and Tomorrow. New Delhi: Indian Council of Medical Research 1989. p 115-25.
[15] Talwar GP, Garg S, Dhar V, Chabra R, Ganju A, Upadhyay SN. Praneem polyherbal cream and pessaries with dual properties of contraception and alleviation of genital infections. Curr Sci 1995; 68: 437-40.
[16] Ross IA. Carica papaya L. In: Ross IA, editor. Medicinal Plants of the World. Totowa, NJ: Humana Press Inc; 1999.

[17] Emeruwa AC. Antibacterial substance from Carica papaya fruit extract. J Nat Products 1982; 45: 123-7.
