Ultrastructural
effect of sildenafil citrate on corpus cavernosum and other genital organs
in female rats
K. kilinç1, M. I. Gnds1,
B. H. Gms1, S. Vatansever2, F. Kaymaz3
1Department of Urology, 2Department
of Histology, University of Celal Bayar, 45010 Manisa, Turkey
3Department of Histology, University of Hacettepe, Turkey
Asian
J Androl 2003 Mar; 5: 37-41
Keywords:
sildenafil; female; clitoris; histopathologic effects
Abstract
Aim: To determine
the ultrastructural effects of sildenafil on the female genital organs.
Methods: Twenty female cycling Wistar albino rats weighing 250
20 g were randomly divided into two groups of 10 each. Rats of one group
were gavaged with 0.5 mg.kg-1.d-1 of sildenafil
3 days in a week for 4 weeks and the other served as the controls. After
cessation of treatment animals were sacrificed by cervical dislocation
under methoxyflurane anaesthesia. The clitoris, vagina, uterus and bartholin
glands were taken at the estrous and were fixed with 10 % formalin solution
for light microscopy and 2.5 % glutaraldehyde and osmic acid for electron
microscopy. Results: Under the light microscope, the fibrocollageous
tissue was found increased, the capillaries enlarged and the connecting
tissue elements increased in the corpus cavernosum in the treated group.
On electron microscopy, increased connective tissue, fibroblasts with
notched nucleus, shorten immature collagen fibers without striation were
seen. Abundant foldings and penetration with collagen bundles were observed
in the basal membrane. Large connection complexes, especially gap junctions
among the wide capillary endothelial cells were observed. Conclusion:
There are evident histological changes due to sildenafil citrate in female
rat corpus cavernosum. The clitoris and bartholin glands were the most
effected organs. While the histopathological changes of clitoral tissue
could be expected, an increase in the mass of bartholin gland was surprised.
1 Introduction
Sildenafil citrate has been
used widely in the treatment of erectile dysfunction (ED) with various
etiologies. The drug, a pyrazolo-pyrimidinyl-methylpiperazine compound,
is a selective inhibitor of the cyclic guanosine monophosphate (cGMP)-
specific phosphodiesterase type 5 (PDE5) [1, 2]. It enhances the relaxation
effect of nitric oxide (NO) on the corpus cavernosum by inhibiting the
PDE5, which is responsible for the degradation of cGMP [3]. The inhibition
of PDE5 by sildenafil citrate increases the cGMP levels in the corpora,
causing smooth muscle relaxation and blood flow increase into the penis,
whenever there is local release of NO by sexual stimulation. This is the
main action of sildenafil on erection [3, 4].
Nowadays, there are many publications about
the beneficial effects of sildenafil on women with sexual dysfunction,
but its long term ultrastructural effects on the target tissues, especially
the female genital organs, are not well understood. The present study
was designed to investigate the histopathological effects of sildenafil
on the clitoral corpus cavernosum and other genital organs in female rats
by light and electron microscopy.
2 Materials and methods
2.1 Animals and treatment
Twenty female cycling
Wistar albino rats weighing 250?0 g were used and housed in standard pathogen
free (SPF) conditions. They were randomly divided into two groups of 10
animals each. Rats of one group were gavaged 0.5 mg.kg-1.d-1 of sildenafil
3 days in a week for 4 weeks as suggested by Ishikura F, et al.
(Am Urol Ass 95th Annual Meeting, Atlanta- Georgia, J Urol 2000 Abstract
No. 887) and the other served as the controls. The dose is less than that
for the humans on per kg body weight basis and is much less than the conventional
dose for rats. After cessation of treatment, vaginal smears were obtained
from animals at estrous when the vaginal orifice was dilated and had lighter
colour as compared with those at proestrous. A drop of water was placed
into the vagina and was aspirated several times. The aspirate was transferred
onto a slide and made a smear. It was dried, soaked for 5 seconds in absolute
methyl alcohol and again dried in air at room temperature. The slide was
placed in 1/20 Giemsa solution for 30 minutes and then rinsed in water.
It was observed under microscope after dryness. Flat and irregular large
cornified epithelial cells were observed at estrous. Animals at estrous
were sacrificed by cervical dislocation under methoxyflurane anaesthesia.
The clitoris, vagina, uterus and bartholin glands were dissected and fixed
in 10 % formalin for light microscopy and in 2.5 % glutaraldehyde and
osmic acid for electron microscopy. The slides were evaluated by 3 histologists
on a blind basis.
2.2 Light microscope examination
Slides were washed overnight
with tap water and were then dehydrated through a graded series of ethanol
(50 %, 60 %, 70 %, 85 %, 95 % and 100 %), 30 minutes for each step. They
were incubated in a 50:50 mixture of 100 % ethanol and xylene for 30 minutes
and followed by two washes in xylene for 1 h. After that, they were transferred
to xylene and paraffin embedding mixture for 30 minutes. Transverse sections
(5 µm) were taken and dewaxed under 60
overnight. Sections were immersed in xylene for 1 h and rehydrated through
a graded series of ethanol (100 %, 95 %, 80 %, 70 % and 60 %) for 2 minutes
in each concentration and were then washed in tap water. They were stained
with haematoxylin and eosine (H-E). Slides were mounted using entellan
and covered with coverslips prior to viewing and photography under the
Olypmpus BX-40 light microscope.
2.3 Electron microscope examination
After fixation, the specimens were stained
with uranyl acetate and processed through standard dehydration in graded
ethanol before infiltration and embedded in Epon. The semi-thin sections
were stained with toluidine blue-azur II before examined under an electron
microscope; ultrathin sections were cut on a Leica Ultracut R ultramicrotom
and stained with uranyl acetate-lead citrate before viewing with a Zeiss
95 M electron microscope.
3 Results
3.1 Clitoris
Under the light microscope,
no clitoral epithelial changes were observed, while the surrounding fibro-collageous
tissue was found increased in the treated group; capillaries were enlarged
and connecting tissue elements were increased in the corpus cavernosum
(Figure 1).
Figure
1. Semi-thin section of clitoris of treated group (100).
Under the electron microscope
in the treated group, the semi-thin sections indicated that the number
of elements and connecting tissue fibers of the corpus cavernosum were
increased; in the ultrathin sections, increased connective tissue and
fibroblasts with notched nucleus and shortened immature collagen fibers
without striations were observed. These fibroblasts with euchromatic nuclei
were accepted as active. Newly synthesized collagen fibers were also found
in the connective tissue (Figure 2a).
In semi-thin sections of the controls, collagen fibers of the connective
tissue were observed less in amount and fibroblasts were not activated
(Figure 2b).
Figure
2a. Active fibroblasts and increased collagen fibers in corpus cavernosum
of treated group (EM 10000, F: fibroblast, C: collagen, asterisk: newly
synthesized dense collagen fibers).
Figure 2b. Fibroblasts and collagen
fibers in corpus cavernosum of control group (EM 10000, F: fibroblast;
C: collagen fibers).
In semi-thin sections of
the endothelial capillaries of corpus cavernosum, as expected, no difference
was observed, but in ultrathin sections, in contrary to the stable cells
of the control group, cells were active and the nuclei were granulated.
The basal membrane surrounding the wide capillary endothelial cells in
the corpus cavernosum was seen as a straight line just under the endothelial
cell membrane. In addition, the foldings of basal membrane were exaggerated
in some areas. The collagen bundles were penetrating the basal membrane
of the corpus cavernosum under the endothelial cells in several microscopic
fields (Figure 3).
Figure
3. Large endothelial cell and basal membrane in corpus cavernosum
of (A) treated group; (B) control group (EM 7250, E: endothelial cells;
BM: basal membrane).
There was no significant
difference in the small capillary endothelium in both the control and
treated groups, while the large capillary endothelial changes were observed
in the treated group (Figure 4).
Figure
4: Endothel and basal membrane of the small capillaries in corpus
cavernozum of (A) treated group; (B) control group (EM 6250, CL: capillary
lumen, BM: basal membrane, E: endothel) .
The connection complexes,
especially the gap junctions, among the wide capillary endothelial cells
were widened in the treated group (Figure
5).
Figure
5. Connection complexes between endothelial cells of small capillary
in corpus cavernosum of (A) treated group; (B)control group (EM 10000,
GJ: gap junctions).
3.2 Vagina
In light microscopic
examination, the stratified squamous epithelium of vagina was found to
be shed in the treated group, while it was normal in the control group.
Additionally, both the connective
tissue and the cellular elements of the stroma beneath the epithelium
were increased in the treated animals; the connective tissue was compact
and dense.
In electron microscopic analysis,
semi-thin sections of the vagina revealed a similar picture in regard
to the epithelium; increased connective tissue due to collagen fibers
was observed as seen in the clitoris. Active fibroblasts were also found
in vaginal sections similar to clitoral sections.
3.3 Bartholin gland
The gland was macroscopically
enlarged in the treated group. Under the light microscope, columnar cells
with mucus secreting pale cytoplasm and small basal nuclei were observed
in the treated group with a hyperplasia of the cytoplasmic secreting granules
of the gland cells. Young and activated fibroblasts were increased and
newly synthesized collagen fibers in the stroma of clitoris were observed
(Figure 6).
Figure
6. Semi-thin section of bartholin gland in (A) treated group ; (B)control
group (400).
3.4 Uterus
There were no significant changes in
the uterus in the treated group as compared with the controls (Figure
7).
Figure
7. Semi-thin section of uterus in (A) treated group; (B) control group
(200).
4 Discussion
During the last 10 years,
there has been a great development in regard to the pathophysiology and
treatment of ED. Unfortunately, only a few studies have been focused on
the sexual dysfunction of women. It was pointed out that 18 %~76 % of
women complained of sexual dysfunction [5].
Recently, it has been shown
that women with sexual dysfunction can be treated with vasodilators [6-10].
Some researchers pointed out that both the clitoral and vaginal blood
flow were partially regulated by NO [6, 8, 9, 11, 12]. Further studies
should be done to assess the role of cGMP-specific PDE5 in clitoris and
vagina. It is suggested that sildenafil citrate used in the treatment
of ED could also be an important candidate for the treatment of women
sexual dysfunction in the future.
Recent reports pointed out
that sildenafil citrate could be used safely in sexual dysfunction of
post menopausal women [13]. For this reason, we investigated the histopathological
effects of sildenafil on the genital organs of female rat.
Enlargement of capillary
in clitoris was observed in our study. This enlargement will undoubtedly
result in an increase in blood flow in the clitoral tissue. To overcome
the difficulty of clitoreal arousal as a result of atherosclerosis in
the postmenopausal period, this affirmative effect of sildenafil on tissue
level may be helpful.
Aging and atherosclerotic
vascular diseases decreased the ratio of clitoral cavernosal smooth muscle/connective
tissue [6], but the effect of clitoral fibrosis on women sexual dysfunction
was not clear. In our study, increased cavernosal smooth muscle and surrounding
fibrocol-lagenous tissue have been observed. In addition, connective tissue
fibers, especially the young and activated fibroblasts, were increased.
As a result, plenty newly synthesized collagen fibers were seen in the
stroma of clitoris.
Sildenafil citrate increased
the vaginal lubrication feeling in women with sexual dysfunction [6].
We observed that in the treated group the connecting tissue elements,
the cellular elements in the stroma and the vaginal capillaries beneath
the epithelium were increased. These findings support the view that the
improvement of lubrication can be due to the increased blood flow and
number of stromal elements in the vagina.
An increase in connective
tissue and dense collagen fibers in corpus cavernosum was demonstrated.
Fibroblastic activation and increase of dense collagen fibers could be
irreversible, so prolonged using of sildenafil citrate may result in fibrosis
in both clitoral and penile tissues. Sildenafil citrate could improve
erectile function by widening the gap junctions, as indicated in the present
study.
It can be seen that the clitoris and Bartholin
glands were the organs most affected by sildenafil. The clitoral changes
could be expected, but an increase in the mass of Bartholin gland somewhat
bewildered us.
References
[1] Jeremy
JY, Ballard SA, Naylor AM, Miller MA, Angelini GD. Effects of sildenafil,
a type-5 cGMP phosphodiesterase inhibitor, and papaverine on cyclic GMP
and cyclic AMP levels in the rabbit corpus cavernosum in vitro. Br J Urol
1997; 79: 958-63.
[2] Balard SA, Gingell CJ, Tang K, Turner LA, Price ME, Naylor AM. Effects
of sildenafil on the relaxation of human corpus cavernosum tissue in vitro
and on the activities of cyclic nucleotide phosphodiesterase isozymes.
J Urol 1998; 159:2164-71.
[3] Medina P, Segarra G, Vila JM, Domenech C, Martinez-Leon JB, Lluch
S. Effects of sildenafil on human penile blood vessels. Urology 2000;
56: 539-43.
[4] Moreira SG, Brannigan Jr RE, Spitz
A, Orejuela FJ, Lipshultz LI, Kim ED. Side-effect profile of sildenafil
citrate (Viagra) in clinical practice. Urology 2000; 56: 474-6.
[5] World Health Organisation. The ICD-10 Classification of mental and
behavioral disorders: Clinical Descritions an Diagnostic Guidelines. EHO:
Genova; 1992.
[6] Berman JR, Goldstein I. Female Sexuel Dysfunction. Urology Clinics
of North America 2001; 28/2: 405-16.
[7] Shenn WW, Urosevich Z, Clayton
DO. Sildenafil in the treatment of female sexual dysfunction induced by
selective serotonin reuptake inhibitors. J Reprod Med 1999; 44: 535-42.
[8] Rajfer J, Aronson WJ, Bush PA,
Dorey FJ, Ignarro LJ. Nitric oxide as a mediator of relaxation of the
corpus cavernosum in response to nonadrenergic noncholinergic neurotransmission.
N Engl J Med 1992 Jan 9; 326: 90-4.
[9] Burnett AL. Nitric oxide in the penis: physiology and pathology. J
Urol 1997; 157: 320-4.
[10] Wagner G, Saenz de Tejada I. Update on male erectile dysfunction.
BMJ 1998;316: 678-82.
[11] Andersson KE, Wagner G. Physiology
of penil erection. Physiol Rev 1995; 75: 191-236.
[12] Medina P, Segarra G, Vila JM, Domenech C, Martinez-Leon JB, Lluch
S. Effects of sildenafil on human penile blood vessels. Urology 2000;
56: 539-43.
[13] Kaplan SA, Reis RB, Kohn IJ, Ikeguchi EF, Laor E, Te AE, et al.
Safety and efficacy of sildenafil in postmenopausal women with sexual
dysfunction. Urology 1999; 53: 481.
home
Correspondence
to: Dr. M. Ilker Gndz,
Department of Urology, Medical Faculty, Celal Bayar University, 45010
Manisa, Turkey.
Tel: +90-236-232 3133 Fax: +90-236-237 0213
E-mail: ilker_gunduz@hotmail.com
Received 2002-06-27 Accepted 2002-12-17
|
