Spatial and temporal expression of germ cell nuclear factor in murine epididymis Zong-Yao Zhou1, 3, Chen Xu1, Qiang-Su Guo1, Yuan-Xin Hu2, Yong-Lian Zhang2, Yi-Fei Wang1 1Department of Histology &
Embryology, Shanghai Second Medical University, Shanghai 200025, China Asian J Androl 2004 Mar; 6: 23-28 Keywords: germ cell nuclear factor; epididymis; spatial and temporal expressionAbstractAim: To investigate the spatial and temporal expression of germ cell nuclear factor (GCNF) in mouse and rat epididymis during postnatal period. Methods: The epididymal sections from different postnatal days were stained for GCNF by the indirect immunofluorescence technique and digital photographs were taken by a Carl Zeiss confocal microscope. Results: GCNF was first detected on day 12 in mouse epididymis and day 14 in rat epididymis. The highest expression of GCNF was observed on day 35 in both mouse and rat epididymis. In adults, GCNF exhibited a region-specific expression pattern, i.e., it was expressed predominantly in the initial segment, caput and proximal corpus of rat epididymis and was abundant in the proximal corpus of mouse epididymis. GCNF could be found in the nuclei of the principal, apical, narrow, clear and halo cells. Conclusion: GCNF may play an important role in epididymal differentiation and development and in sperm maturation. 1 Introduction The germ cell nuclear factor (GCNF), also known as retinoid acid receptor-related testis-associated receptor (RTR) or NR6A1, is an orphan receptor of the nuclear receptor superfamily. Originally isolated from mouse cDNA libraries, homologs of GCNF have been identified in humans, Xenopus laevis and zebrafish [1-4]. During embryonic development, GCNF gene is expressed in early embryonic stem cells, trophoblasts and neuronal precursor cells, suggesting that the receptor may participate in the regulation of neurogenesis and be of importance to the embryonic development [5-7]. In the adult, GCNF expression is abundant in the testis and ovary [8-11]. In the testis, GCNF is most abundant in round spermatids. Therefore, GCNF may participate in the regulation of gene transcription during a specific stage of spermato-genesis. Two transcripts of approximately 7.4 Kb and 2.3 Kb are present in the testis, but only the larger one is found in somatic cells [10]. Recently, we found that GCNF is also expressed in the epithelia of mouse epididymis. Apart from the 7.4 Kb transcript, another 3.1 Kb transcript is also present in the mouse epididymis. The expression levels of both GCNF transcripts in mouse epididymis are down-regulated by androgen treatment and the two mRNAs (7.4 & 3.1 Kb) encode for the same protein. In situ hybridization and indirect immuno-fluorescence results show that GCNF is abundant in the proximal corpus of adult mouse epididymis [12]. The epididymis is a multifunctional male accessory organ. It provides an adequate environment for the final maturation of sperm. Gross morphology shows that the highly convoluted single tubule of the adult epididymis is divided into four major segments: initial segment, caput, corpus and cauda. Each region has distinct functions and expresses specific proteins. The proper development and functional maintenance of the epididymis are essential for its normal function. The epididymis develops from the Wolffian duct during embryogenesis. During postnatal development, epididymis epithelial cells undergo rapid proliferation and expansion [13]. Beginning with an undifferentiated epithelium, the epididymis undergoes a series of changes resulting in the establishment of a fully differentiated epithelium, which differs in morphology, gene expression and function throughout its whole length [14]. The spatial and temporal patterns of gene expression are critical to the development and maintenance of a fully functional epididymis and a normal intact epididymis is essential for the functional maturation of the sperm [14, 15]. The purpose of this study is to investigate the spatial and temporal pattern of GCNF expression in murine epididymis during the postnatal period, in order to highlight the possible relationship between GCNF expression and epididymal development and function. 2 Materials and methods 2.1 Animals BALB/c mice and SD rats were purchased from the Animal Center of the Chinese Academy of Sciences and divided into nine groups of 4-6 animals each according to their postnatal age, i.e. at day 8, 10, 12, 14, 28, 35, 49 and 70 and month14 after birth. 2.2. Anti-GCNF antiserum Rabbit polyclonal anti-GCNF antiserum was prepared as described previously [12, 16]. 2.3. Indirect immunofluorescence staining The epididymides were fixed in Bouin's for 10-18 hours, embedded in paraffin, cutted into 6 mm sections and mounted onto 2 % aminopropyltriethoxysilane-coated slides. For immunofluorescence staining, 1:800 diluted anti-GCNF antiserum was applied overnight at 4 and 1:50 diluted FITC-conjugated goat-anti-rabbit IgG (Jackson Immunoresearch Laboratories, Inc, USA) was incubated for 2 hours in the dark at room temperature. As a negative control, serial sections were put through the same procedure with the preimmune serum replacing the primary antibody. Digital photographs of fluorescent sections were taken using an LSM-510 laser scanning confocal microscope and attached software (Carl Zeiss, Germany). The immunofluorescence stained sections were then restained with hematoxylin and eosin and photographs were taken for cell discrimination. All of the images were edited with Adobe Photoshop 6.0. 3 Results 3.1 GCNF expression in postnatal epididymis In the mouse, there were no GCNF positive cells in the epididymis on day 8-10 (data not shown). On day 12, the onset of GCNF expression was detected in only a few positive nuclei in the low columnar undifferentiated cells in the caput, corpus and cauda (Figure 1b, c and d). It is not a non-specific staining as the negative control stained with preimmune serum did not show any staining (Figure 1a). By day 28 and 35, the number of GCNF positive cells increased progressively and was distributed evenly throughout the whole epididymis (Figure 1e, f, g, and h). On day 35, most cells in the corpus epididymis had GCNF positive staining (Figure 1g), while the number of GCNF positive cells started to decline in the distal cauda (Figure 1h). On day 49, GCNF expression in the initial segment, caput and proximal corpus of the epididymis reached the highest levels and the number of GCNF positive cells declined dramatically in the distal corpus and cauda (Figure 1 i, j, k and l). From day 70 to month 14, the GCNF expression pattern in the epididymis was the same as that of the adult (56 days) as we formerly reported [12]. It was mainly expressed in proximal corpus epididymis (Figure 1m, n, o and p), i.e., most cells in the proximal corpus showed strong positive staining (Figure 1o). Figure
1. GCNF expression in mouse epididymis during postnatal period. The GCNF expression pattern in the rat epididymis was a little different from that of the mouse. First, GCNF expression started on day 14 (Figure 2a, b, c and d) instead of on day 12 in the mouse. Second, on day 35, almost all the cells in the rat epididymis had strong GCNF positive staining (Figure 2e, f, g and h). Third, from day 49 to month 14, most cells in the initial segment of caput and proximal corpus showed strong positive staining and there were almost no GCNF positive cells in the distal corpus and cauda (Figure 2i, j, k, l, m, n, o and p). The number of GCNF expressing cells in the mouse and rat epididymal segments during postnatal period is shown in Table 1. Figure
2. GCNF expression in rat epididymis during postnatal period. Table 1. Number of GCNF positive cells in mouse and rat (within parentheses) epididymal segments.
3.2 Cell localization of GCNF in epididymis The cell types of GCNF expression could be easily identified on the same section used for immunofluorescence and then stained with hematoxylin and eosin. From the postnatal day 35 to month 14, positive GCNF staining could be detected in the nuclei of all cell types (principal, basal, apical, narrow, clear and halo cells) in the epididymis of mice and rats (Figure 1q, r and s and Figure 2q, r and s). The number of the GCNF positive narrow cells and clear cells did not obviously change during the postnatal period (data not shown). In adults (70 days) and old (14 months) rats, most clear cells in the distal corpus and cauda still showed strong positive staining for GCNF (Figure 2q, r and s), while principal cells in this region were almost negative (data not shown). Interestingly, GCNF positive staining could be found in both the nuclei and the cytoplasm of the narrow cells (Figure 1q, r and s and Figure 2m). 4 Discussion During postnatal development, the epididymis undergoes a series of morphological changes including the cellular differentiation, the formation of the blood-epididymis barrier and the functional interactions between epididymal epithelia and sperm, which transmit through the epididymis to acquire motility and fertilizing capability. The histogenesis and differentiation of rat epididymis has been intensively investigated [1, 17, 18]. The development of the rat epididymal epithelium during the postnatal period has been divided into three stages, i.e., the undifferentiated stage (day 1-14), the stage of differentiation (day 15-48), and the stage of expansion (from day 49 on) [1, 17, 18]. However, the processes governing epididymal development from the newborn to the adult is a poorly understood area in the field of developmental and reproductive biology. The proper development of the epididymis requires molecular signaling pathways and the restricted spatial and temporal expression of several key genes [1, 2] and the GCNF gene may be one of them. A unique spatial and temporal pattern of GCNF expression in murine epididymis was described in this study. GCNF begins to be expressed in the mouse epididymis on day 12 or 14 in rats. At this time the epididymal epithelium is essentially undifferentiated. When the epididymal epithelium begins to differentiate (day 15-28), GCNF expression increases gradually. The highest expression of GCNF was observed on day 35 in both mice and rats and at that time dramatic morphological changes occurred in the epididymal epithelium [1, 17, 18]. From day 49 until adult, epididymal epithelia were fully differentiated and GCNF exhibited a region-specific expression, i.e., it was expressed predominantly in the initial segmen-t, the caput and proximal corpus of the epididymis. Our results indicate that GCNF expression during the postnatal period is closely associated with the differentiation of the epididymal epithelium. Although the precise nature of the contribution by the epididymal epithelium to maturation of spermatozoa is not completely understood, the gene products synthesized in the epithelium are thought to play region-specific roles in creating the microenvironment conducive to acquisition of fertilizing capability. It is generally accepted that the initial segment, the caput and proximal corpus are crucial for spermatozoa to acquire their motility and fertilizing capability [2, 19]. So the regional expression pattern of GCNF in mouse and rat epididymides suggests that it might be involved in the regulation of target gene expression, which might be important for the maturation of spermatozoa. Regional differences in the expression of a number of genes have been observed in the epididymal epithelium, such as D/E, CRES, CRBP E-RABP EAP-1, HE2, GPX, GGT and SGP-2, which were mainly expressed in the initial segment and caput [2, 19], and CD52/HE5, P26h, CAII-IV, a-mannosidase and b-galactosidase mainly expressed in the corpus [2, 19]. Since GCNF is a transcription factor and mainly expressed in the proximal corpus in adult mice and the initial segment, the caput and proximal corpus in adult rats, it might regulate more than one gene in the epididymis. Further investigation is required to identify the relationship between GCNF and these genes. Our results also showed that GCNF positive staining could be found in the nuclei of principal, basal, apical, narrow, clear and halo cells. GCNF expression in principal cells is age-dependent, which is not observed in narrow cells and clear cells. The exact reason for this difference is presently unknown. Although the precise function of different cell types in the epididymis has not been clearly elucidated, each type of cell may have different functions [1, 17]. So the significance of GCNF expression in narrow cells and clear cells might be different from that of principal cells. It is interesting that the cytoplasm of narrow cells also showed strong GCNF positive staining. We do not know whether GCNF in the narrow cells is a transcription factor or it is secreted into the lumen of the epididymis by narrow cells through holocrine cells as suggested by Martan and Allen [20]. In summary, GCNF is expressed in the developing epididymis and exhibits a time- and region-specific expression pattern in both the mice and rats. It is suggested that it may play an important role in epididymal epithelial differentiation and involved in sperm maturation. Acknowledgments The work was supported by the National Natural Sciences Foundation of China, No. 30070391, the "973" Basic Research Funding Scheme of China (G 1999055901) and the Science and Technology Development Foundation of Shanghai Family Planning Commission (No.03JG 05009). References [1] Chen
F, Cooney AJ, Wang Y, Law SW, O'Malley BW. Cloning of a novel orphan receptor
(GCNF) expressed during germ cell development. Mol Endocrinol 1994; 810:
1434-44.
